4-110kw Q235 Carbon Structural Steel Biomass Boiler System Blower and Induced Draft Fan

4-110kw Q235 Carbon structural steel biomass boiler system blower and induced draft fan

The 4-110kW biomass boiler system blower and induced draft fan are made of Q235 carbon structural steel, offering robust performance, high efficiency, and durability. Designed to optimize biomass boiler operations, they ensure reliable air supply and exhaust for various industrial applications.

1.It is capable of outputting a higher outlet pressure while providing more gas flow with lower noise. Stable operation at higher media temperatures.
2.The fan speed can be flexibly set by matching different pulley diameters to make the fan run at the highest efficiency point and reduce energy waste.
3.Motor sliding guides are provided for easy tensioning of the belt to reduce energy loss due to belt slack.
4.The bearing housing is reserved for temperature and vibration sensor mounting positions, for convenient to install the fan operation monitoring device.
5.Use liquid lubricant, it is not necessary to open the bearing housing to replace and fill the oil. The bearing housing is provided with an observation window for easy observation of the quality and stock of the lubricating oil.
6.The bearing housing uses a labyrinth mechanical seal, a unique Leak proof oil design inside, a vent hole at the top, and a sealant on the joint, completely eliminating the possibility of oil leakage in the bearing housing.
7.The impeller is annealed to completely eliminate the internal stress generated during welding, ensuring that the impeller does not undergo creep and cracks.
8.The impeller is subjected to a high standard of dynamic balance correction to ensure stable operation of the fan.
9.After the production is completed, all products are tested for running and vibration values for reliable operation.

The following datas are only part of performance of our product.
If you can't find the datas you need, pls send us your performance requirements
we will provide you customized design service.

Pursue excellent quality, make perfect product!

We are a professional centrifugal fan manufacturer integrating R&D, manufacturing, production, sales and after-sales service. We have 70 years of fan manufacturing and project experience. If you have fan needs, you can leave your fan requirements and parameter information, and our technical engineers will provide you with professional fan solutions.
